Your companion for everyday life and exciting bike tours

Whether asphalt or gravel track, your new all-terrain bike feels at home on almost any surface with its approximately 5.4 cm wide tires, offering a wide range of uses. The lightweight and durable Bafang M400 mid-drive motor provides smooth and reliable support with its 80 Nm of torque. Together with the fully integrated 630 Wh battery, it ensures that both commutes and longer excursions with the TERRA 4.0i are enjoyable for extended periods. This all-rounder is compliant with German road traffic regulations (StVZO) and equipped with a 90 lux LED headlight, hydraulic disc brakes, and mudguards. With a maximum permissible weight of 135 kg, you can easily attach luggage to the rear rack. A Fischer spiral lock is already included.

The bike is delivered pre-assembled.

Features

• All-terrain bike
• Frame height: approx. 43 cm (Wave)
• Hydraulic Disc brake
• SR Suntour suspension fork
• Bafang M400 mid-drive motor
• Battery capacity: 630 Wh
• Electricity (battery): 17.5 Ah
• Range: approx. 150 km
• Seatpost diameter: approx. 3.16 cm
• Bafang M400 mid-drive motor
• Seat clamp: Aluminum quick release
• Number of gears: 10
• Gear type: Derailleur gears
• Shifter type: Trigger
• Shifter brand: Shimano
• Lighting: LED
• Front light: 90 lux
• Maximum permissible weight: 135 kg
• Incl. Spiral lock
• App connectivity
• 5 support levels
• Push assist

Dimensions/Weight:

• L x W x H: approx. 188 x 26 x 126 cm
• Approx. 26 kg

Scope of delivery:

• All Terrain E-Bike Terra 4.0 (2023 model), frame size 43 cm
• Spiral lock
• Assembly instructions
• Warranty card

The bike is delivered pre-assembled.

The manufacturer reserves the right to replace and install certain components with exclusively equivalent or superior alternative components.

Assembly and quick start instructions
